Product Details:
Payment & Shipping Terms:
|
| Power: | 150w | LED Driver: | Meanwell |
|---|---|---|---|
| IP Rating: | IP50 | CCT: | 2700-6500K |
| Beam Angle: | 120 Degree | Material: | Aluminum+PC Optical Lens |
| CRI: | >80 | Lumens: | 18750lm |
| Highlight: | low bay led shop lights,led low bay lights |
||
Exclusive Low Bay 150w Lumileds chips& Meanwell driver,dimmable,CRI>80,5 years warranty
Low Bay Light 150w Specification:
| Product Model | Power | LED Quantity | Luminous Flux | Light Efficiency | CRI | CCT | Beam Angle |
| LY-HB55150-XX | 150W | 210pcs | 18750 lm | 125 lm/W | 70/80 | 2700-6500K | 120d |
| Product Model | Input Voltage | Product Size | IP Grade | Life Span | Material | Power Range |
| LY-HB55150-XX | AC100-240V | 330x328x100mm | IP50 | 50,000 hrs | Alumium+PC | 150/200/250w |
Advantages:
1) Perfect mounted in high location on warehouse/parking place/workshop,etc.
2) Lumileds chips plus Meanwell driver, UGR:18, 5 years warranty.
3) 1-10V Dimmable and microwave motion sensor both available.
4) Lock catch and chain as standard equipped for installation.
Carefully read the installation instructions and ensure the mains supply is isolated before installation. Please follow the safety information overleaf before carrying out any installation. Please retain this lealet for future reference.
Quality Control
Quality guarantee is based on storing,installing,operating and maintaining correctly in the normal operation condition.
It is not included in our maintaining range when installing inappropriately,breaking the operating rules,and leading to the products damaging.
Our company will maintain the right to either repair,parts replacing,or products exchange during the quality warranty period.
Operation and Storage Condition
Operation Ambient Temperature -20 to +50, Relative Humidity 20~90%
Input Voltage 100~240V AC, 50/60Hz
Storage Ambient Temperature -20 to +65, Relative Humidity 5~95%
Mounting Height : Suitable for 5~12m height
FAQ:
