IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty.

Name: IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty.
Brand: Leyond
SKU: LY-ST20040-XX
Rating: 5 (161 reviews)

Large Image : IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty.

Product Details:

Place of Origin:	China
Brand Name:	Leyond
Certification:	CE ROHS ENEC CB
Model Number:	LY-ST20040-XX

Payment & Shipping Terms:

Minimum Order Quantity:	4
Price:	Negociable
Packaging Details:	carton box
Delivery Time:	10-15 days
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	10000-30000/month

Contact Now

Detailed Product Description

Product Name:	LED Street Light 40W	Ip Rating:	IP 65
Warranty(year):	5	Application:	Roadway Lighting Fixture
Lamp Body Material:	Aluminum	Working Temperature(℃):	-30 - 60
Lamp Luminous Efficiency(lm/w):	130	Color Temperature(cct):	WW :2700K-3200K NW:4000K-4500K PW:5000K-6500K
Highlight:	outdoor led street light , led street lamp

01. structure

IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty. 0

02. Features:

Suitable for the street lighting at highways, urban roads and secondary roads, stadiums, sidewalks,

residential areas, industrial areas, squares, parks, schools, villas, gardens and other places.

03. specification:

Par NO Parameter	LY-ST20040PW	LY-ST20040WW	LY-ST20040NW
Input voltage	AC100V～240V 50/60HZ // DC12-24V
System consumption(W)	40	40	40
Luminous flux(lm)	5300	5200	5100
Chip Brand	Luxeon 3030/Leyond3030	Luxeon3030/Leyond 3030	Luxeon3030/Leyond 3030
Beam Angle	150*65 DEG	150*65 DEG	150*65 DEG
CRI	＞70
Color Temperature	Warm white:2700-3200K / Neutral white:4000-4500K / Pure white:5000-6500K
LED Driver	MEAN WELL XLG-50H
Luminous efficiency(lm/w)	＞130
Lifespan(hrs)	＞50000
IP Rating	IP65
Dimmable	YES＆NO	YES＆NO	YES＆NO
Size(mm)	410x200x90	410x200x90	410x200x90
Net Weigh(kg)	2.8	2.8	2.8
Package Size(mm)	465255145	465255145	465255145
Package Quantity(Pcs)	1	1	1
Gross Weigh(kg)	3.3	3.3	3.3

04. package:

IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty. 1

05. production

IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty. 2

06. testing

IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty. 3

07. exhibition

IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty. 4

IP65 LED Street Lighting 40W with die custing aluminum housing for 5 years warranty. 5
