Product Details:
Payment & Shipping Terms:
|
| Product Name: | Modular Led Light | Power: | 500w Avaliable |
|---|---|---|---|
| LED Chip: | Bridgelux | LED Driver: | Meanwell |
| Luminous Efficiency: | 150lm/w | PF: | >0.95 |
| CCT: | 2700K-5700K | IP Rating: | IP65 |
| Warranty: | 5 Years | Beam Angle: | 24°/36°/60°/90°/160° |
| Website: | Www.leyond.com.cn | Skype: | Lysales25 |
| Applications: | Billboard,playground,warehouse,tennis Court | ||
| Highlight: | led outdoor flood lights,commercial outdoor led flood light fixtures |
||
Quick Details:
1. Type: LED Flood Light
2. Power:500w
3. Luminous flux:6000lm
4. Input Voltage:AC100-240V
5. Warranty:5years
6. IP Rating:IP65
7. LED Chip:bridgelux
8. Driver:Meanwell
Description:
Excellent heat sink led module design, easier maintenance, waterproof IP65,Optic PC lens, light transmittance>97%
Features:
1. Modular design,each single module 30-50w,we use 30pcs 1w power leds that encapsulated with Bridgelux chips,which soldered on the Aluminium PCB board,this is for better heat sink.
2. World top Calss MeanWell Driver with 5years warranty at least,high lumens and more stability
3. multi-optional optical lense,multi-optional beam angles: 24°/36°/60°/90°(flood light), 160°(high mast light), 145°x90°(tunnel light), 150°x70° (street light)
4. IP Rating:IP65(waterproof)
5. Lamp Power: 60w/80w/100w/120w/150w/200w/250w/300w/400w/500w
6. Certificate: CE,RoHS,UL, SAA
|
Model |
LY-ST23500PW
|
|
Product Name |
500w Modular Led light
|
|
Modules number |
10PC
|
|
Power
|
500w
|
|
Input Voltage |
AC90~305V 50/60Hz
|
|
Input Current
|
2.32A/220VAC
|
|
Chip Brand
|
Bridgelux
|
|
Led Qty
|
300pcs
|
|
Driver Brand
|
2PCS* Meanwell HLG-240-36A
|
|
Warranty
|
5 Years
|
|
Power factor
|
>0.99/115VAC
>0.98/230VAC |
|
Power efficiency
|
>90%
|
|
Luminous flux
|
60000lm
|
|
Luminous efficiency
|
120lm/W
|
|
CRI
|
>70
|
|
CCT
|
2700K-6500K
|
|
Beam Angle
|
24° 36° 60° 90°/160°
|
|
Carton Size
|
79×63×20cm
|
|
Gross weight
|
21KG
|
|
IP Rating
|
IP65
|
|
Meterial
|
Aluminum +PC
|
|
Certification
|
CE&ROHS
|
Operation and Storage Condition:
• Operation Ambient Temperature -30 to +60°C, Relative Humidity 20~90%
• Input Voltage 90-305V AC, 50/60Hz
• Storage Ambient Temperature -40 to +85°C, Relative Humidity 5~95%
• Mounting Height : Suitable for 10-15M height
Quality Warranty:
Quality guarantee is based on storing,installing,operating and maintaining correctly in the normal operation condition.
It is not included in our maintaining range when installing inappropriately,breaking the operating rules,and leading to the products damaging.
Our company will maintain the right to either repair,parts replacing,or products exchange during the quality warranty period.
Why Choose Us:
1.Strong R&D Capability
We keep ourselves updating with the world's latest technology,and cultivate a group of skillful professional engineers,which enable us to make high quality products with the advanced technology.
2.Wide Product Range
We can manufacture outdoor lightings which include LED Flood Light,LED High Bay Light,LED Street Light,LED canopy light and so on.
3.Mature Production Technique
We have advanced full automotive machines for production,we have exclusive formula to solve all the problems which may appears during production.
4.Super OEM/ODM Ability
We can offer OEM/ODM services,we have the ability to customize you products for led chips, led lens,or led lights even others can't do.
