Product Details:
Payment & Shipping Terms:
|
| Power: | 150W | LED Chip: | Lumileds 3030 SMD |
|---|---|---|---|
| LED Driver: | Meanwell HLG-150 | IP Rating: | IP65 |
| CCT: | 2700-6500K | Warranty: | 5 Years |
| Beam Angle: | 150X65degree | Package: | 75cm×40cm×23cm (2 PCS ) |
| GW: | 9.6kg | Luminous Flux: | 18750lm |
| Dimmable: | YES&NO | CRI: | >80 |
| Pole Diameter: | 60mm | ||
| Highlight: | outdoor led street light,led street lamp |
||
Product Description:
1. Save 80% more energy compared with traditional lighting fixtures
2. Easy to install and use, secure and reliable
3. No UV or RF interference, No mercury or lead
4. Light body is made of good quality die casting aluminum, exiguity and unique design, excellent heat dissipation
5. Long life span>50000hrs
6. High brightness, low consumption, green for environment
7. AC85-305V in different countries and regions.AC12/24V led driver is also available
8. Potection grade is IP65
Features:
1. Absolutely unique mold,make your lighting special and fantastic.
2. Perfect Light Distribution Solution:Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.
3. Anti-glare and uniform light level to avoid any visual discomfort.
4. High quality power supply, input voltage 100-277V. The power efficiency is more than 90%, power factor greater than 0.98, UL compulsory certification.
5. Adopting 3030 led light sources and LEYOND lens technology, 8% light efficiency higher than the same type lights in the market, with higher light transmittance up to 98%.
6. Duct type thermal design, reduce the weight of the light and ensure good heat dissipation, lower luminous decay, and also extend life span of the leds. Adopting the popular CHEM modular design, effectively reduce the following maintenance cost.
7. Low energy consumption,matching high efficiency constant-current driver, 60% energy saving; with good resistance to over-current, over-voltage, lightning, high temperature, which fully ensure long life span and high stability of the products.
8. Durable lights with long life span up to 50000 hours; No need frequent replacements of lights and regular maintenance.
9. Green environmental protection, no UV light and infrared radiation, no mercury pollution.
Specification:
| Model | Inptut voltage | Sysem consumption | Luminous flux | Chip Brand | Beam Angle |
|---|---|---|---|---|---|
| LY-ST20150PW | AC100V～240V 50/60HZ |
150W | 18750lm | 3030 | 150*65° |
| LY-ST20150WW | 17400lm | ||||
| LY-ST20150NW | 18000lm |
| Model | CRI | Color Temperature | LED Driver | Luminous efficiency | Lifespan | IP Rating |
|---|---|---|---|---|---|---|
| LY-ST20150PW | ＞80 | WW:2700-3200K NW:4000-4500K PW:5000-6500K |
MEAN WELL HLG-150H |
＞120lm/W | ＞50000h | IP65 |
| LY-ST20150WW | ||||||
| LY-ST20150NW |
| Model | Dimmable | Size(mm) | Net Weight | Package Size(mm) | Gross Weight |
|---|---|---|---|---|---|
| LY-ST20150PW | YES＆NO | 642x290x120 | 8.8kg | 720*370*200 | 9.6 |
| LY-ST20150WW | |||||
| LY-ST20150NW |
Aging Test:
Our Services:
MOQ: 2pcs
Port: Shenzhen, Zhongshan, Guangzhou
Sample availability: Yes
Supply capability: 1000 pcs/day
Payment: T/T, Western Union, Paypal.
Shipment: ocean or air transportation, international express
Normal lead time: 5days for sample order;10 days for production order
Payment condition: 30% before production, 70%before delivery
FAQ:
1. How many watt you have for Sword led Street light ?
---- 30w, 40w, 50w, 60w 100w 120w 150w
2. How is the warranty?
----We could offer 5 years warranty, and during our warranty:
1). Products returned within the warranty period must be Leyond product number & date code.
2). Products of unknown sources or without valid marking will not be accepted.
3). Replacement items will be sent together with customer's next order shipment.
3. What's your delivery time?
---- For sample order our delivery time is 3-5 working days. For General order, for about 8 working
days.
4. What kind of payment and shippmeng do you use?
----T/T,Westen Union,Paypal
----Fedex,UPS,DHL,TNT,HongKong Post,EMS or other ways of shippment.
5. Would you do OEM or ODM orders?
---- Sure, OEM and ODM orders are welcome
